1560nm Sub-picosecond Pulsed Fiber Laser

Connet 1560nm sub-picosecond pulsed fiber laser adopts the all-fiber design and is an all polarization-maintaining fiber laser based on SESAM passive mode-locked technology. The stable linearly polarized femtosecond laser output can be achieved through the optimized optical path, which is highly reliable and maintenance-free.

Specifications:

Parameter

Unit

Specification

Min

Typ.

Max

Part no.



VFLP-1560-M-fs

VFLP-1560-M-fs

Center wavelength

nm

-

1563±5

-

Pulse width*

fs

100

-

1000

Repetition rate

MHz

40

-

80

Spectral width

nm

10

-

-

Output power

mW

>2

>100

Beam quality

M2

<1.1

Polarization



Linear Polarization

Polarization Extinction Ratio (PER)

dB

20

22

-

Output power stability

%

-

±1

±2

Pulse peak stability

%

-

-

5

Output isolation

dB

35

-

-

Operating temperature

+10

-

+50

Storage temperature

-40

-

-85

Supply voltage

VDC

5.5-12

Output fiber type



PM1550-XP

Output fiber length

m

>0.5

Connector



FC/APC (other options available)

Dimension

mm

150(L)x125(W)x25(H)

*Notes: Pulse width can be narrower upon request.


Ordering Information:

· VFLP-1560-M-fs-FA: 1560nm Femtosecond Mode-locking Fiber Laser (Seed Laser)

· VFLP-1560-M-fs-PA-FA: 1560nm Femtosecond Mode-locking Fiber Laser (Seed Laser + Pre-amplifier)

· M: Module

Features:

• SESAM passive mode-locked all PM fiber design

• Narrow spectral width<1nm

• Robust and compact

• Sub-picosecond pulse width, MHz repetition rate

• Low amplitude noise

• Maintenance-free operation

Applications:

• Seed laser for fiber laser or fiber amplifier

• Time precision detection

• Test and measurement

• LiDAR

• R&D
